5 nti npo Capacitive kov
5 nti npo Capacitive kov
Qauv: FT6960
Hom Lub Npe: Head Sun Co., Ltd
Xim ciam teb: Dub
Qauv: P+G
Interface: IIC
Kov cov ntsiab lus: 5 Points
Tag nrho Thickness: 2.75mm
Qhov Loj: 82.88 ± 0.1mm * 174.3 ± 0.1mm
Hauj lwm lawm
Product Description:
Khoom kos duab:
Khoom Specifications:
5 nti npo Capacitive kov | |
Cov yam ntxwv zoo | |
Khoom Loj | 5 nti |
Cov qauv khoom | P+G |
Daim duab Dimension | 82.88 ± 0.1 hli * 174.3 ± 0.1 hli |
Saib cheeb tsam | 62.18mm * 110.22 hli |
Tag nrho Thickness | 2.75mm ib |
Cov yam ntxwv hluav taws xob | |
IC hom | CST340 |
Kov cov ntsiab lus | 5 Cov ntsiab lus |
Interface | IIC |
Kev khiav hauj lwm voltage | 3.3V |
Cov kev xaiv ua haujlwm tshwj xeeb | |
Hom hnab looj tes | |
Waterproof Level | |
Antistatic Test | |
Cov khoom siv sab nraum zoov | |
Riot Level / IK Qib | |
Waterproof ua haujlwm hom | |
Khoom yam ntxwv | |
Npog Lens | PMMA, Thickness=2.0 hli |
ITO-FLIM | Thickness 0.55 hli |
OCA | Thickness 0.2 hli |
Environmental yam ntxwv | |
Kev Ua Haujlwm Kub | -20~60℃ |
Cia Kub | -30~70℃ |
Kev Ntsuam Xyuas Kev Ntseeg | |
Kev kub ceev cia | T=70℃, 72H |
Tsawg-kub Cia | T=-30℃, 72H |
High-temperature\High-humidity Storage | T=60℃ 90%,72H |
Kub poob siab | (-20 ﾟ C (30min) ← (5min Max.) → 60 ﾟ C (30min))=50 Set |
Electro Static Discharge | Cua paug: ± 8KV, Hu rau paug: ± 4KV |
Hardness | ≥6H |
Ball Drop Test | 64g 40cm, Tsis muaj kev tawg ntawm qhov chaw taw tes rau 3 zaug |
FPC Bending Test | Lub vojvoog dabtsi yog khoov R1.0 hli, ntau tshaj peb zaug |
Nco tseg: | |
1. Muaj peev xwm ntau lawm los xyuas kom meej qhov khoom xa tuaj.
●3,000 square meters Hoobkas thiab tsis muaj plua plav rhiav, ntau tshaj 150 tus neeg ua haujlwm.
●8 kab khoom ntawm G+G& G+F+F thiab 6 cov kab khoom ntawm CTP+LCM kev sib txuas ua ke tag nrho. Cov zis txhua hli tuaj yeem ncav cuag 40,000pieces.
● Yellow sensor teeb txheej txheem + laser sensor txheej txheem.
2. Pab neeg muaj kev paub dhau los
Ntau tshaj 10 xyoo dhau los ntawm kev tshaj lij engineer pab pawg.
3. Txais OEM& ODM.
Cov neeg siv khoom tuaj yeem txiav lawv tus kheej cov khoom. Koj tsuas yog xav tau xa cov duab kos thiab cov qauv rau peb. Peb tus engineer yuav ntsuas rau koj.
4.Ntev Technology
Siv mainstream kov screen daj lub teeb txheej txheem technology.
5.Strict thiab ua tiav cov kev tswj xyuas zoo thiab muaj peb tus kheej lub chaw kuaj xyuas. Yog li cov neeg siv khoom tsis tas yuav txhawj xeeb txog qhov zoo.
Q: Lub tshuab ua haujlwm twg tuaj yeem txhawb nqa?
A: Txhawb Android, Windows, Linux, IOS.
Q: Kuv puas tuaj yeem yuav lub vijtsam kov yam tsis them tus nqi tsim kho?
A: Yog. Koj tuaj yeem yuav peb cov khoom uas twb muaj lawm yam tsis tau them tus nqi txhim kho
Q: Lub neej ntev ntawm lub vijtsam kov yog dab tsi?
A: Peb lub vijtsam kov txhawb ntau dua 50 billion zaug kov.
Q: Dab tsi yog qhov zoo ntawm capacitive kov cov ntxaij vab tshaus dhau cov tshuaj tiv thaiv kov?
A: 1.Kev puas tsuaj zoo thiab tsis yooj yim rau khawb.
2. Zoo kov rhiab heev.
3. Nws tuaj yeem txhawb nqa ntau qhov kov.
Q: Qhov zoo ntawm G+G qauv yog dab tsi?
A: 1.Nws yog ib qho nyuaj thiab tsis yooj yim rau khawb.
1.Nws yog corrosion-resistant.
2.Lub teeb transmittance siab, tshaj 91%.
Peb Honour thiab Certifications:Lub taub hau Sun tau ua tiav dhau ntawm kev lag luam high-tech, audited tsum thiab ISO9001 zoo tswj kev ntsuam xyuas.
Kev nug:
Thov ua tib zoo sau daim foos kom zoo thiab peb yuav tiv tauj koj raws li cov ntaub ntawv tiv toj hauv qab no.
Cim npe nrov: 5 nti npo capacitive kov, Tuam Tshoj, lwm tus neeg, manufacturers, hoobkas, customized, ua nyob rau hauv Suav teb
